KUB
Aerospace Titanium SeriesHigh-Performance Anti-Vibration Ball Nose End Mill
| FEATURES: |
|---|
|
1.KUB is the upgraded version of UB, featuring the latest G18 coating to further extend tool life and wear resistance when machining difficult-to-cut materials such as Inconel and titanium alloys.
|
|
2. The unique S-type ball nose design delivers superior surface finish after machining.
|
| 3. Specifically engineered for 3D curved surface milling of difficult-to-cut materials, ideal for semi-finishing and finishing operations. |
| Working Materials Hardness Level: Extremely difficult-to-cut materials, such as Inconel 718, nickel-based superalloys, stainless steel, and titanium alloys. |
Applicable Milling Methods:  Rough milling, semi-finish milling, finish milling |
| Applicable Coolant Ways: Wet |
| Type NO. | Diameter | Flute Length | O.A.L | Shank Dia |
|---|---|---|---|---|
| D1 | L1 | L3 | D2 | |
| KUB0102 | R0.5 | 2 | 50 | 4 |
| KUB0152 | R0.75 | 3 | 50 | 4 |
| KUB0202 | R1 | 4 | 50 | 6 |
| KUB0202S | R1 | 4 | 50 | 4 |
| KUB0302 | R1.5 | 6 | 50 | 6 |
| KUB0302S | R1.5 | 6 | 50 | 4 |
| KUB0402 | R2 | 8 | 50 | 6 |
| KUB0402S | R2 | 8 | 50 | 4 |
| KUB0502 | R2.5 | 10 | 50 | 6 |
| KUB0602 | R3 | 12 | 50 | 6 |
| KUB0802 | R4 | 16 | 60 | 8 |
| KUB1002 | R5 | 20 | 75 | 10 |
| KUB1202 | R6 | 24 | 75 | 12 |
| KUB1602 | R8 | 32 | 100 | 16 |
