| Features: |
|
1. Specially designed for both roughing and finishing copper, aluminum alloy.
|
|
2. Exquisite sharpening technique, which features side milling has a good surface finish.
|
|
3. As a breakthrough, AEM's surface finish and Ra value are superior to AES and AET after machining.
|
|
4. A second choice for milling copper, aluminum alloy which specifically requires good surface finish and high Ra value.
|
|
5. Ra value of full-size AES could reach 0.2~0.3um after milling.
|
| Working Materials Hardness Level: Copper、Aluminum alloy |
Applicable Milling Methods:  Finishing ,Semi-finishing , Roughing |
Applicable Coolant Ways: Emulsion machining  Oil machining,MQL(Mist) machining  Dry Machining |
| Type No. | Diameter | Flute Length | O.A.L. | Shank Dia. |
|---|---|---|---|---|
| D1 | L1 | L3 | D2 | |
| AES0203S | 2.0 | 6 | 50 | 4 |
| AES0203 | 2.0 | 6 | 50 | 6 |
| AES0303S | 3.0 | 8 | 50 | 4 |
| AES0303 | 3.0 | 8 | 50 | 6 |
| AES0403S | 4.0 | 11 | 50 | 4 |
| AES0403 | 4.0 | 11 | 50 | 6 |
| AES0503 | 5.0 | 13 | 50 | 6 |
| AES0603 | 6.0 | 16 | 50 | 6 |
| AES0603L | 6.0 | 32 | 75 | 6 |
| AES0803 | 8.0 | 20 | 60 | 8 |
| AES0803L | 8.0 | 45 | 100 | 8 |
| AES1003 | 10.0 | 25 | 75 | 10 |
| AES1003L | 10.0 | 50 | 100 | 10 |
| AES1203 | 12.0 | 30 | 75 | 12 |
| AES1203L | 12.0 | 55 | 100 | 12 |
| AES1603 | 16.0 | 40 | 100 | 16 |
| AES1603L | 16.0 | 50 | 120 | 16 |
| AES2003 | 20.0 | 45 | 100 | 20 |
| AES2003L | 20.0 | 60 | 120 | 20 |
