| Features: |
|
1. The special design is suitable for surface, slot, side and 3D milling of steel material hardness up to HRc52.
|
| Working Materials Hardness Level: Good at steels with hardness HRc22-52. E.g. P20, NAK80, SKD61(HRc52), S136(HRc52) etc. |
Applicable Milling Methods:  Finishing  Semi-finishing  Roughing |
| Applicable Coolant Ways: MQL (Mist) Machining Dry Machining , Emulsion Machining and Oil Machining |
| Type No. | Diameter | Flute Length | Corner R | Neck Dia. | O.A.L. | Thread Size | Spanner Type No. |
|---|---|---|---|---|---|---|---|
| D1 | L1 | R | D2 | L2 | M | ||
| X-UXR0803 | 8.0 | 8.0 | 0.3 | 7.8 | 12.1 | M5-3P | K08 |
| X-UXR0805 | 8.0 | 8.0 | 0.5 | 7.8 | 12.1 | M5-3P | K08 |
| X-UXR0810 | 8.0 | 8.0 | 1.0 | 7.8 | 12.1 | M5-3P | K08 |
| X-UXR1005 | 10.0 | 10.0 | 0.5 | 9.8 | 16.1 | M7-3P | K10 |
| X-UXR1010 | 10.0 | 10.0 | 1.0 | 9.8 | 16.1 | M7-3P | K10 |
| X-UXR1205 | 12.0 | 12.0 | 0.5 | 11.7 | 20.3 | M8-3P | K12 |
| X-UXR1210 | 12.0 | 12.0 | 1.0 | 11.7 | 20.3 | M8-3P | K12 |
| X-UXR1605 | 16.0 | 16.0 | 0.5 | 15.6 | 25.7 | M10-3P | K16 |
| X-UXR1610 | 16.0 | 16.0 | 1.0 | 15.6 | 25.7 | M10-3P | K16 |
| X-UXR1620 | 16.0 | 16.0 | 2.0 | 15.6 | 25.7 | M10-3P | K16 |
| X-UXR2010 | 20.0 | 20.0 | 1.0 | 19.5 | 31.1 | M12-3P | K20 |
| X-UXR2020 | 20.0 | 20.0 | 2.0 | 19.5 | 31.1 | M12-3P | K20 |
| X-UXR2030 | 20.0 | 20.0 | 3.0 | 19.5 | 31.1 | M12-3P | K20 |
| X-UXR2530 | 25.0 | 25.0 | 3.0 | 24.4 | 39.3 | M16-3P | K25 |
| X-UXR2550 | 25.0 | 25.0 | 5.0 | 24.4 | 39.3 | M16-3P | K25 |
