| 刀具特色: |
|
1. 特殊幾何圖形設計、專門適用於<高速高進給>之面溝銑切削。
|
|
2. 不適用於<側銑切削>。
|
| 適用切削材料: 適用於HRc32~65之鋼材料加工,例如:NAK80/P20/SKD61(HRc52)/SKD11(HRc62)等。 |
適用切削方式:  粗銑  中銑  精銑 |
| 適用冷卻方式: 油霧切削 乾式氣冷 水溶性、油性切削 |
| 型號 | 直徑 | 頸徑 | R角 | 刃長 | 有效長 | 全長 | 柄徑 |
|---|---|---|---|---|---|---|---|
| D1 | D3 | R | L1 | L2 | L3 | D2 | |
| UOR0203 | 2.0 | 1.8 | 0.3 | 0.8 | 5 | 50 | 6 |
| UOR0205 | 2.0 | 1.8 | 0.5 | 0.8 | 5 | 50 | 6 |
| UOR0308 | 3.0 | 2.7 | 0.8 | 1.2 | 8 | 50 | 6 |
| UOR0310 | 3.0 | 2.7 | 1.0 | 1.2 | 8 | 50 | 6 |
| UOR0405 | 4.0 | 3.6 | 0.5 | 1.6 | 10 | 50 | 6 |
| UOR0405L | 4.0 | 3.6 | 0.5 | 1.6 | 10 | 75 | 6 |
| UOR0410 | 4.0 | 3.6 | 1.0 | 1.6 | 10 | 50 | 6 |
| UOR0410L | 4.0 | 3.6 | 1.0 | 1.6 | 10 | 75 | 6 |
| UOR0610 | 6.0 | 5.4 | 1.0 | 2.5 | 13 | 50 | 6 |
| UOR0610M | 6.0 | 5.4 | 1.0 | 2.5 | 13 | 75 | 6 |
| UOR0610L | 6.0 | 5.4 | 1.0 | 2.5 | 13 | 100 | 6 |
| UOR0615 | 6.0 | 5.4 | 1.5 | 2.5 | 13 | 50 | 6 |
| UOR0615M | 6.0 | 5.4 | 1.5 | 2.5 | 13 | 75 | 6 |
| UOR0615L | 6.0 | 5.4 | 1.5 | 2.5 | 13 | 100 | 6 |
| UOR0810 | 8.0 | 7.2 | 1.0 | 3.5 | 16 | 60 | 8 |
| UOR0810L | 8.0 | 7.2 | 1.0 | 3.5 | 16 | 100 | 8 |
| UOR0820 | 8.0 | 7.2 | 2.0 | 3.5 | 16 | 60 | 8 |
| UOR0820L | 8.0 | 7.2 | 2.0 | 3.5 | 16 | 100 | 8 |
| UOR1010 | 10.0 | 9.0 | 1.0 | 4.0 | 20 | 75 | 10 |
| UOR1010L | 10.0 | 9.0 | 1.0 | 4.0 | 20 | 100 | 10 |
| UOR1020 | 10.0 | 9.0 | 2.0 | 4.0 | 20 | 75 | 10 |
| UOR1020L | 10.0 | 9.0 | 2.0 | 4.0 | 20 | 100 | 10 |
| UOR1220 | 12.0 | 11.0 | 2.0 | 5.0 | 25 | 75 | 12 |
| UOR1220L | 12.0 | 11.0 | 2.0 | 5.0 | 25 | 100 | 12 |
| UOR1230 | 12.0 | 11.0 | 3.0 | 5.0 | 25 | 75 | 12 |
| UOR1230L | 12.0 | 11.0 | 3.0 | 5.0 | 25 | 100 | 12 |
